- Flexible discharge configuration – Choose from 1-way or 2-way discharge, with each barrel nozzle individually adjustable through 90° to switch between horizontal, diagonal or vertical air patterns.
- High induction multi-stream design – A series of barrel nozzles break the supply jet into multiple mini-jets, generating intense mixing with room air. This results in rapid velocity decay, high momentum and far-reaching yet low-velocity throw profiles for superior comfort.
- Wide system compatibility – Suitable for flush-ceiling installation or free-hanging mounting. Compatible with CAV and VAV systems, and capable of handling low-temperature supply air (≥ 5 °C) with ΔTₛᵤₚₚₗᵧ-room ≥ -16 K.
- Customisable slot configurations – Available in 1 to 8 slot rows (more on request). Standard neck length 1200 mm (1195 mm face), custom lengths available upon request.
- Installation options – Choose flanged or flangeless profiles, modular or continuous run format (joining strips optional), and optional mounting frames or side-entry plenums for concealed connections.
- High comfort performance – With uniform temperature distribution and high induction values, the LMC-AD supports an ADPI (Air Diffusion Performance Index) of ≥ 90% ensuring occupants experience consistent comfort conditions.
SmartAir
Linear Multistream Ceiling Diffuser
The SMARTEMP LMC-AD is a premium linear slot ceiling diffuser offering adjustable 1- or 2-way multi-stream mini-jet discharge. Designed for high-comfort environments, it delivers thorough air mixing and uniform temperature distribution through its advanced high-induction technology. Ideal for CAV or VAV systems including low-temperature supply air applications.
